Accessories

Accessories for bearings

To compliment the various bearings available from HB, we also manufacture a wide range of bearing accessories. Made with the same care and attention to detail as our bearings, our accessories are available in both imperial and metric sizes. Sizes can be standard or non-standard, and a wide variety of materials can be specified to suit your requirements.

Many of the more popular items are already manufactured and held in stock. Please contact us for details of our current stock-holding.

If your special project calls for a bespoke bearing accessory design, our design department will be pleased to offer you assistance in this area. HB’s design department combines a state-of-the-art CAD/CAM system with our 50 years of experience. We have the knowledge to help deliver a solution to your bespoke requirements!

What follows are examples of the many types of accessory we can offer, with a further list of items that can be manufactured to order, shown at the end. If you cannot see what you are looking for, please do not hesitate to contact us with your requirements.

SEATING RINGS FOR THRUST BEARINGS (top)

HJ series of Angle RingsHB Bearings manufacture all sizes of metric rings and imperial rings. Many sizes are available from stock.

Types manufactured include:

  • U2XX, U3XX, U4XX
  • SLTS, SMTS, SHTS

Seating rings shown here, SMTS 1 1/4", U336, U412.



ANGLE RINGS (HJ RINGS) (top)

HJ series of Angle Rings HB Bearings manufacture all sizes of metric rings and imperial rings. Many sizes are available from stock.

  • HJ 1000
  • HJ 200 & HJ 200E
  • HJ 2200 & HJ 2200E
  • HJ 2300 & HJ 2300E
  • HJ 300 & HJ 300E
  • HJ 330 & HJ 330E


Imperial sizes HJL and HJM manufactured
to suit individual bearings.

Angle rings shown here, HJ338E, HJ228E, HJ206E.


WITHDRAWAL SLEEVES (top)

Withdrawal sleevesSleeves can be manufactured with non-standard bores, lengths, threads, tapers or completely special. Sleeves can be supplied with oil inspection ducts on bore, taper or both. Many sleeves with non-standard bores held in stock.

Withdrawal Sleeves shown here, H2322-100mm, H3038-170mm, H316-2 3/8".







ADAPTOR SLEEVES (top)

Adaptor sleevesSleeves can be manufactured with non-standard bores, lengths, tapers, threads or completely special. Sleeves can be supplied with oil inspection ducts on bore, taper or both. Many sleeves with non-standard bores held in stock.

Adaptor Sleeves shown here, AH 3130 145mm bore, AHX 2224 115mm bore, AHX 2317 80mm bore.




BRONZE BUSHES (top)

HB Bearings can manufacture and modify standard bronze bushes, or alternately manufacture special sizes to order. HB manufacture plain or flanged bushes in BS 1400:LG2 or alternative materials to suit your requirements.

           FIGURE OF EIGHT                                                   HELICAL-LEFT OR RIGHT

Figure of 8 bronze bush                                    Helical bronze bush

                    AXIAL                                                                       ELLIPTICAL

Axial bronze bush                                    Eliptical bronze bush

                 ANNULAR

Axial bronze bush

SPECIAL IMPERIAL SIZE ROLLERS (top)

Special Imperial size rollers

Special imperial size rollers.

Sizes shown here:-

15⁄16” ø x 1 7⁄32” long

1 1⁄8” ø x 2” long

3⁄4”ø x 2” long




HB can manufacture imperial size rollers with special diameters and lengths. We can supply them with or without blended ends and in bearing steel or stainless steel or special alloys. Small quantities can be manufactured.


SPECIAL METRIC SIZE ROLLERS (top)

Special metric size rollers

Special metric size rollers.

Sizes shown here:-

10mm ø x 50mm long

60mm ø x 58mm long

15mm ø x 50mm long



HB can manufacture metric size rollers in special diameters, lengths or both, We can supply them with or without blended ends and in bearing steel or stainless steel or special alloys. Small quantities can be manufactured.

OTHER BEARING ACCESSORIES (top)

Other bearing accessories available from HB include:

  • non-standard tab washers in special materials, manufactured to order
  • non-standard lock nuts, manufactured to order
  • non-standard lock nuts with locking screws, manufactured to order
  • oil pick-up rings, manufactured to order
  • eccentric collars, manufactured to order
  • non-standard snap rings, manufactured to order
  • non-standard locating rings, manufactured to order
  • non-standard inner races, metric and imperial, manufactured to order
  • non-standard shims, manufactured to order
